Specifications performance and weight of pneumatic rubber fender
|
Specification
D×L（m）
|
Initial pneumatic pressure 0.05Mpa
|
Initial pneumatic pressure 0.08Mpa
|
||||
|
Sphere Weight(KG)
|
R(KN)
|
GEA(KJ)
|
Sphere Weight(KG)
|
R(KN)
|
GEA(KJ)
|
|
|
0.5×1.0
|
25
|
64
|
6
|
25
|
85
|
8
|
|
0.6×1.0
|
32
|
74
|
8
|
32
|
98
|
11
|
|
0.7×1.5
|
50
|
137
|
17
|
50
|
180
|
24
|
|
1.0×1.5
|
80
|
182
|
32
|
80
|
239
|
45
|
|
1.0×2.0
|
100
|
257
|
45
|
125
|
338
|
63
|
|
1.2×2.0
|
120
|
297
|
63
|
165
|
390
|
88
|
|
1.35×2.5
|
165
|
427
|
102
|
226
|
561
|
142
|
|
1.5×3.0
|
315
|
579
|
153
|
370
|
761
|
214
|
|
1.7×3.0
|
405
|
639
|
191
|
436
|
840
|
287
|
|
2.0×3.5
|
590
|
875
|
308
|
632
|
1150
|
430
|
|
2.5×4.0
|
1050
|
1381
|
663
|
1110
|
1815
|
925
|
|
2.5×5.5
|
1333
|
2019
|
943
|
1410
|
2653
|
1317
|
|
3.0×5.0
|
1880
|
2000
|
1050
|
2155
|
2709
|
1571
|
|
3.0×6.0
|
2160
|
2488
|
1312
|
2470
|
3292
|
1888
|
|
3.3×4.5
|
2020
|
1884
|
1175
|
2300
|
2476
|
1640
|
|
3.3×6.0
|
2300
|
2783
|
1675
|
2600
|
3652
|
2338
|
|
3.3×6.5
|
2700
|
3015
|
1814
|
3080
|
3961
|
2532
|
|
3.3×10.6
|
4403
|
5257
|
3067
|
5020
|
6907
|
4281
|
|
4.5×9.0
|
6554
|
5747
|
4752
|
7470
|
7551
|
6633
|
|
4.5×12.0
|
8739
|
7984
|
6473
|
9960
|
10490
|
9037
|
|
Note: The weight is the fender weight (excluding protective sleeve), with weight error of±10% and counterforce error pf±10%
|
||||||
Specifications of others can be customized according to customer required
We can assure you of workable price ,excellent quality and prompt delivery
Structure of pneumatic rubber fender for ship
Out adhesive: Protective cord layer and inner adhesive have high tensile strength and abrasion resistance .
Cord layer : Strong layer of the pneumatic rubber fender is made from winding the high –strength polyamide fibre cord fabric .
Inner adhesive : The cord layer of pneumatic rubber fender assures no gas leakage from the compressor .
End-flange: The end-flange is a part to fix air valve component ,buried metal part and the cord layer and used for hoisting ,and filling ans discharging gas .The structure of the end-flange is shown in Fig .
Note
1．Frenquently check whether the airbag spheroid is damaged and whether the pressure is normal ,and the valve core must be replaced every six months.
2．The steel wire should wrap the rubber pipe ,when tying steel wire to pneumatic rubber fender in case the the fender is stabbed .
3. The surace or subject next to the pneumatic rubber fender can’t be hard and sharp-point in case the fender is stabbed .
4. The accessories and jip’s nut can’t be loose when testing the internal pressure .
5. When applying the pneumatic rubber fender ,the rope net should be reliable ,the steel wire used for hanging metal parts and the hook
Storage of Pneumatic rubber fender ：
1. When not using for a long time ,wash the fender surface ,dry up and fill in sufficient right amount of compressed air to lay in a cool ,dry and well-ventilated place .
2. The storage place of pneumatic rubber fender should be far away from heat source .
3. Try to keep fender away from acid ,alkali,grease and organic solvents.
4. When not applying the fender ,the pneumatic rubber fender can’t be piled up and heavy itiems can’t be piled on the fender .
